ball mill mining machine

Price: 67741.0~70968.0 USD
Payment Terms: T/T,L/C,D/A,D/P,WU;negotiable
Place of Origin: Henan, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: MQY-2145
Production Capacity: 150 sets per year
Delivery Date: 30 working after receiving ...
Type: Mill
diameter:2100mm: length:4500mm
Means of Transport: Ocean
Packing: 20GP OR 40GP,40HQ,FR contai...
Application: Ore
Brand Name: ZHONGDE
main motor:280kw: speed:23.8r

1.Customized products
2.ISO9001:2008
3.Effective volume:13.8m3
4.Capacity:25-8/h
5.Discharging size:0.6-0.074

 Specification:
1.ISO9001:2008
2.professional manufacture with 50years
3.durable liner,whole life service,discharging evenly
4.customized
Shell rotation speed(r/min)      Ball load(t)    Feeding size(mm)      Discharging size(mm)       Power(kw)     Total weight(t)                                                                  Tianjin, Qingdao ,Shanghai 20-30 days after receiving payment                                                                        Export standard container 20GP OR 40GP, 40HQ, FR container, in bulk, the spare parts in wooden case
What Are These Machines and How Do They Work?
A Ball Mill grinds material by rotating a cylinder with steel grinding balls, causing the balls to fall back into the cylinder and onto the material to be ground. The rotation is usually between 4 to 20 revolutions per minute, depending upon the diameter of the mill. The larger the diameter, the slower the rotation. If the peripheral speed of the mill is too great, it begins to act like a centrifuge and the balls do not fall back, but stay on the perimeter of the mill.
The point where the mill becomes a centrifuge is called the "Critical Speed", and ball mills usually operate at 65% to 75% of the critical speed.
Ball Mills are generally used to grind material 1/4 inch and finer, down to the particle size of 20 to 75 microns. To achieve a reasonable efficiency with ball mills, they must be operated in a closed system, with oversize material continuously being recalculated back into the mill to be reduced. Various classifiers, such as screens, spiral classifiers, cyclones and air classifiers are used for classifying the discharge from ball mills.
This formula calculates the critical speed of any ball mill. Most ball mills operate most efficiently between 65% and 75% of their critical speed.
Ball mill is the key equipment for grinding after the crush process, and it is widely used in the manufacture industries, such as cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics.
It also can be used for the dry and wet grinding for all kinds of ores and other grind-able materials.
Types:
Mill could be sorted as following:
As per the grinding media: ball mill, rod mill and AG Mill (without grinding media).
As per material discharging mode: wet grid mill, dry grid mill & overflow mill.
As per driving mode: side & central driving. The former is more popular now.
As per driving configuration:
a. Asynchronous motor driving: Asynchronous motor + Reducer + Pinion +Girth gear
b. Synchronous motor driving: Synchronous motor+ Air clutch+ Pinion +Girth gear
c. Asynchronous motor + reducer + diaphragm coupling
Structure of Ball mill:
The machine is composed of feeding part, discharging part, turning part and driving part (reducer, small driving gear, electric motor and electric control).
The quill shaft adopts cast steel part and the liner is detachable. The turning gearwheel adopts casting hobbing process and the drum is equipped with wear-resistant liner, which has good wear-resistance.
Working principle:
The ball mill is horizontal cylindrical rotation device, driven by brim gearwheel.
There are two chambers and grid. Material goes into the first chamber through the feeding inlet. Inside the first chamber, there are stage liners and ripple liners as well as steel balls. The shell rotates so as to generate electricity, and this force brings ball to a certain heighSpecification:
Model
Cylinder
Effective volume(m3)
Max.ball loading(t)
Speed (r/min)
Capacity(t/h)
Discharging size(mm)
Diameter(mm)
Length(mm)
MQY-1530
1500
3000
4.5
8
30
6.32.8
0.30.074
MQY-1545
1500
4500
6.7
12
30
93.8
0.30.074
MQY-1830
1830
3000
6.7
12
26.6
12.54.5
0.30.074
MQY-1845
1830
4500
10.5
19
26.8
15.56
0.30.074
MQY-2130
2100
3000
9.2
16
23.8
185.8
0.30.074
MQY-2136
2100
3600
11
20
23.8
226.8
0.30.074
MQY-2145
2100
4500
13.8
25
23.8
258
0.30.074
MQY-2230
2200
3000
10
18.5
21.3
236.9
0.30.074
MQY-2245
2200
4500
15.2
28
21.3
26.88.5
0.30.074
MQY-2430
2400
3000
12
22
21.3
267
0.30.074
MQY-2436
2400
3600
14
26
21.3
33.58.8
0.30.074
MQY-2445
2400
4500
17.8
30
21.6
4211
0.30.074
